Bosch Rexroth Ball Nut SEM E C
- Single Ball Nut with Adjustable C-shaped central flange
- Available in a range of sizes from Ø16mm to Ø50mm nominal diameter
- Seals fitted
- Right hand thread direction
- Please enquire for
- Alternative sizes not listed
- Front Lube version
- Left Hand version
- Matching Ballscrew Shaft
- Click here for full technical data and load ratings
Price excl. VAT
Key benefits
- Smooth functioning due to the principle of internal recirculation
- Especially smooth running due to the optimal pick-up of balls from the raceway
- Adjustable-pre-tensioned single nut
- High load rating due to large number of balls
- Short nut length
- No protruding parts, nut is easily mounted
- Smooth outer shell
- Effective, wiping sealing
- Large range of series available ex stock
- Supplied with an integrated mandrell so can be easily mounted on to any Bosch Rexroth Ballscrew Shaft regardless of accuracy grade
Bosch Rexroth Part Numbers available:
R151201055, R151204075, R151206055, R151211075, R151217055, R151221075, R151224075, R151228055, R151231075, R151234075, R151237055, R151239055, R151241075, R151244075, R151245055, R151247075, R151249075, R151251075, R151254075, R151255055, R151257076, R151259055, R151264075, R151267076, R151269055, R151274075, R151277056
Ball Nut Repair - Click here to visit PGM Reball
Did you know we can also refurbish used ballscrews to near new performance in our workshop at PGM Reball? Benefits include a fast turnaround time normally within 24-48 hours and at about a third of the cost of a new ballscrew it makes sense.
